E2E Test Automation with WebdriverIO

WebdriverIO is one of the most powerful tools for automating web application testing. It controls a real browser, interacts with your app the same way a user would, and tells you exactly what passed and what didn't. In this article, I'll walk you through how I built a WebdriverIO automation suite from the ground up — the structure, the patterns, and the real test code behind it.

the implementation

Project Structure

Here's how the project is organized:

javascript

1	automation-teststore-webdriverio/
2	config/
3	production.e2e.conf.js ← separate config for production environment
4	test/
5	helper/
6	generator.js ← random test data generator
7	pageobjects/
8	page.js ← base page (shared logic)
9	homepage.js ← Homepage page object
10	navbar.js ← Navbar page object
11	login.page.js ← Login page object
12	registerPage.js ← Register page object
13	successRegister.js ← Success page object
14	specialspage.js ← Specials page object
15	subnav.js ← Sub navigation page object
16	specs/
17	navbar.spec.js ← Navbar tests
18	loginPage.spec.js ← Login tests
19	registerPage.spec.js ← Register tests
20	wdio.conf.js ← Main configuration file
21	package.json

21 lines

The separation is intentional. Page objects hold the selectors and actions. Spec files hold the test scenarios. They never mix.

Reusable Navbar Component

The Configuration File

Everything starts with wdio.conf.js. This file tells WebdriverIO how to run tests — which browser to use, which files to run, how long to wait, and where to send the report.

javascript

1	const browserName = process.env.BROWSER \|\| "firefox";
2
3	export const config = {
4	runner: "local",
5	framework: "mocha",
6	maxInstances: 10,
7	waitforTimeout: 10000,
8
9	capabilities: [{
10	browserName: browserName,
11	acceptInsecureCerts: true,
12	}],
13
14	reporters: [
15	"spec",
16	["allure", { outputDir: "allure-results" }],
17	],
18	};

18 lines

A few things worth noting here:

Browser is configurable via environment variable. You don't hardcode the browser. Instead, you pass it at runtime:

BROWSER=chrome npx wdio run ./wdio.conf.js

No config change needed to switch browsers.

Test suites are grouped. Instead of running all tests every time, you can run just the suite you need:

javascript

1	suites: {
2	login: ["test/specs/loginPage.spec.js"],
3	register: ["test/specs/registerPage.spec.js"],
4	e2e: [
5	"test/specs/navbar.spec.js",
6	"test/specs/loginPage.spec.js",
7	"test/specs/registerPage.spec.js",
8	],
9	},

9 lines

Run them with:

javascript

1	npm run login # runs only login tests
2	npm run register # runs only register tests
3	npm run e2e # runs the full suite

3 lines

Allure is wired in. Every test run automatically generates a detailed report in allure-results/ that you can open in a browser — showing pass/fail per test, execution time, and error screenshots.

The Page Object Pattern

The most important design decision in this project is the Page Object Model (POM). The idea is simple: every page in the app gets its own class. That class holds all the element selectors and all the actions you can take on that page.

01.

Base Page

javascript

1	export default class Page {
2	open(path) {
3	return browser.url(`https://automationteststore.com/${path}`)
4	}
5	}

5 lines

Every page object extends this base class. So opening any page is just one line.

02.

javascript

1	get loginName() {
2	return $("#loginFrm_loginname");
3	}
4
5	get password() {
6	return $("#loginFrm_password");
7	}
8
9	get loginBtn() {
10	return $('button[title="Login"]');
11	}
12
13	get alertErrorMsg() {
14	return $(".alert-error");
15	}
16
17	async login(loginName, password) {
18	await this.loginName.waitForDisplayed();
19	await this.loginName.setValue(loginName);
20	await this.password.setValue(password);
21	await this.loginBtn.click();
22	}
23	}
24
25	export default new LoginPage();

25 lines

Notice the login() method — it wraps the entire login flow into one reusable action. In any test that needs a logged-in user, you just call:

await loginPage.login("Cahya123", "Cahya123");

One line. No duplicated steps.

03.

The Register page object is larger because the registration form has many fields — first name, last name, email, phone, address, city, region, zip code, country, login name, password, confirm password, and privacy policy checkbox. Each field has its own getter:

javascript

1	get firstName() { return $("#AccountFrm_firstname"); }
2	get email() { return $("#AccountFrm_email"); }
3	get loginName() { return $("#AccountFrm_loginname"); }
4	get password() { return $("#AccountFrm_password"); }
5	get privacyPolicyCheckbox() { return $("#AccountFrm_agree"); }

5 lines

And each validation message has its own getter too:

javascript

1	get minCharFirstnameMsg() {
2	return $('//span[contains(text(), "First Name must be between 1 and 32 characters!")]');
3	}
4
5	get duplicateLoginNameMsg() {
6	return $('//span[contains(text(), "This login name is not available.")]');
7	}

7 lines

This means in the test, you never write raw selectors. You always write human-readable property names.

The Test Data Generator

One of the trickiest problems in registration tests is uniqueness. If every test uses the same login name, the second test will always fail with "duplicate login name." The solution is a random data generator:

javascript

1	import { animals, uniqueNamesGenerator } from "unique-names-generator";
2
3	function generateUniqueName() {
4	let randomName = uniqueNamesGenerator({
5	dictionaries: [animals],
6	length: 1,
7	});
8	while (randomName.length < 10) {
9	randomName += uniqueNamesGenerator({ dictionaries: [animals], length: 1 });
10	}
11	return randomName.substring(0, 10);
12	}
13
14	function generatePassword() {
15	return uniqueNamesGenerator({ dictionaries: [animals], length: 1 });
16	}
17
18	function generatePhonenumber() {
19	return parseInt(Math.random().toFixed(6).replace("0.", ""));
20	}

20 lines

Every time the registration test runs, it generates a unique name, a unique email, a unique phone number, and a unique login name. Tests never collide with each other — or with existing data in the system.

The Test Specs

01.

Navbar Tests

javascript

1	beforeEach(async () => {
2	await browser.maximizeWindow();
3	await homepage.open();
4	});
5
6	afterEach(async () => {
7	await browser.deleteCookies();
8	await browser.refresh();
9	});
10
11	it("should display the logo", async () => {
12	await navbar.logo.waitForDisplayed();
13	expect(navbar.logo).toBeDisplayed();
14	});
15
16	it("navigate to homepage on clicking logo button", async () => {
17	await navbar.logo.click();
18	await expect(browser).toHaveUrl("https://automationteststore.com/");
19	});
20
21	it("dropdown is appear on hovering over account button", async () => {
22	await navbar.accountBtn.moveTo();
23	await expect(navbar.accountDropdownMenu).toBeDisplayed();
24	});
25	});

25 lines

beforeEach runs before every test — maximizes the window and opens the homepage fresh. afterEach clears cookies and refreshes — so every test starts clean, with no leftover session data.

02.

javascript

1	it("Should be able to show message when login with invalid credential", async () => {
2	await loginPage.loginName.setValue("1231231");
3	await loginPage.password.setValue("123123");
4	await loginPage.loginBtn.click();
5	await expect(loginPage.alertErrorMsg).toBeDisplayed();
6	});
7
8	it("Should be able to login", async () => {
9	await loginPage.login("Cahya123", "Cahya123");
10	});
11	});

11 lines

Two scenarios — invalid credentials show an error, valid credentials succeed. Clean, readable, and maintainable.

03.

The register spec is the most comprehensive. It tests every single validation rule the form enforces:

Test	What it verifies
First name empty	Error message appears
First name > 32 characters	Error message appears
Last name empty	Error message appears
Email empty	Error message appears
Address < 3 characters	Error message appears
Address > 128 characters	Error message appears
City < 3 characters	Error message appears
City > 128 characters	Error message appears
Region not selected	Error message appears
ZIP code empty	Error message appears
Login name empty	Error message appears
Login name < 5 characters	Error message appears
Login name > 64 characters	Error message appears
Duplicate login name	"Not available" message appears
Password < 4 characters	Error message appears
Password > 20 characters	Error message appears
Password masked	Input type is `password`
Password ≠ confirm password	Alert error appears
Privacy policy not checked	Alert error appears
All valid data	Redirects to success page

The Allure Report

After every run, results are saved to allure-results/. You can generate and open the visual report with:

javascript

1	npx allure generate allure-results --clean
2	npx allure open

2 lines

The report shows every test by name, pass/fail status, execution duration, and — on failure — the exact error and the line where it happened.

What This Suite Covers

Area	Coverage
Navbar — element visibility	✅
Navbar — all navigation links	✅
Navbar — hover dropdown	✅
Login — valid credentials	✅
Login — invalid credentials	✅
Register — all field validations	✅
Register — duplicate login name	✅
Register — password security	✅
Register — full happy path	✅
Session cleanup between tests	✅
Random test data — no collisions	✅
Multi-browser support	✅
Allure reporting	✅

A WebdriverIO suite built with the Page Object Model is clean, maintainable, and readable by anyone on the team. Selectors live in page objects. Test logic lives in spec files. Random data generators keep tests independent. And Allure reports make results easy to share with clients and stakeholders. When a bug appears, you know exactly which test caught it, what the expected behavior was, and what the app actually did instead.

the testing stack

Every tool chosen with purpose — from feature to assertion.

WebdriverIO

for browser automation and element interaction

Jenkins

runs the load tests automatically as part of the CI/CD pipeline

Allure Report

to visualize test results in a clean, shareable report
